Diamond core drilling machine

REMS Picus S1 diamond core drill Basic-Pack 180010 R220

★ 0.0 (0 reviews)
Sold: 0
Views: 0
Imported from: Germany
Origin: Made in Germany

The REMS Picus S1 Basic-Pack 180010 R220 is the starter kit of the S1 line. 1850 W, 580 rpm, reinforced concrete up to Ø102 mm, Ø132 mm on a stand, masonry up to Ø162 mm, 5.2 kg. Takes REMS diamond core crowns with UNC 1¼ thread.

SKU: 180010 R220
€2,069.80
Stock status: Out of stock
Indicative price
Description

The REMS Picus S1 Basic-Pack 180010 R220 is the starter kit of the S1 line. It includes the drive unit, stabiliser, drilling start aid and steel case; just add a crown. It suits plumbers and HVAC fitters drilling pipe holes by hand. The Picus S1 line uses a 1850 W motor with a load speed of 580 rpm. It drills steel-reinforced concrete up to Ø102 mm hand held and up to Ø132 mm on a drill stand. In masonry and other materials it reaches Ø162 mm. The drive unit weighs only 5.2 kg and works dry or wet. REMS rates a Ø62 mm hole, 200 mm deep in reinforced concrete, at about 3 minutes.

Before ordering, check the largest hole size, the wall or floor material and whether water can be used on site. These three points decide between a drive unit, a Basic-Pack or a set with a stand.

REMS Picus S1 core drill Basic-Pack

Item 180010 R220 includes:

  • Picus S1 drive unit 1850 W with water supply
  • Stabiliser
  • Drilling start aid G ½ UDKB with Ø8 mm drill
  • Allen key size 3, open-ended wrench size 32
  • Steel case

Picus S1 features

  • 1850 W universal motor, load speed 580 rpm.
  • Dry or wet drilling, hand held or on a drill stand.
  • Compact body for drilling flush with walls and in narrow corners.
  • Maintenance-free gear with a safety slip clutch against blocking.
  • Multifunction electronics: soft start, idle speed limiting, overload and blocking protection.
  • Connecting cable with integrated personal protection switch (PRCD).
  • Water supply with adjustable shut-off valve and quick coupling with water stop, ½" hose connection.
  • Ø60 mm clamping throat for the REMS Simplex 2 or REMS Titan drill stand.

Crowns and drill stands

The machine takes REMS UDKB and UDKB LS universal core crowns, 420 mm drilling depth. The UNC 1¼ thread is the REMS standard, so one set of crowns fits every Picus. Compatible stands: REMS Simplex 2 stand (up to Ø202 mm) or REMS Titan stand (up to Ø300 mm, tilting 45°).

Which Picus S1 version to choose

Dust when drilling dry

Drilling concrete, masonry and stone releases fine quartz dust that is harmful to inhale. EN 60335-2-69 requires at least a class M safety extractor. REMS Pull 2 M meets this class and connects directly to the Picus suction port.


Specifications

  • Motor power: 1850 W
  • Voltage: 230 V, 50–60 Hz
  • Load speed: 580 rpm
  • Concrete, steel-reinforced concrete: up to Ø102 mm, Ø132 mm on a drill stand
  • Masonry and other materials: up to Ø162 mm
  • Crown connection: UNC 1¼ male, G ½ female
  • Clamping throat: Ø60 mm
  • Drilling mode: dry or wet, hand held or on a stand
  • Protection: PRCD, safety slip clutch, overload and blocking protection
  • Drive unit weight: 5.2 kg
  • Compatible crowns: REMS UDKB and UDKB LS, drilling depth 420 mm
  • Scope of supply: Picus S1 drive unit 1850 W with water supply; Stabiliser; Drilling start aid G ½ UDKB with Ø8 mm drill; Allen key size 3, open-ended wrench size 32; Steel case
Tags / Keywords: REMS Picus S1 core drill
Optional Accessories
SKU Image Price VNĐ Product name & short description
180000 R220 REMS Picus S1 diamond core drill, drive unit 180000 R220
€1,886.06
REMS Picus S1 diamond core drill, drive unit 180000 R220
The REMS Picus S1 core drill 180000 R220 is the bare drive unit of the S1 line, sold without a steel case. 1850 W, 580 rpm, reinforced concrete up to Ø102 mm, Ø132 mm on a stand, masonry up to Ø162 mm, 5.2 kg. Takes REMS diamond core crowns with UNC 1¼ thread.
180020 R220 REMS Picus S1 diamond core drill Set 62 180020 R220
€2,264.46
REMS Picus S1 diamond core drill Set 62 180020 R220
The REMS Picus S1 Set 62 180020 R220 combines the S1 Basic-Pack with a UDKB Ø62 mm crown. 1850 W, 580 rpm, reinforced concrete up to Ø102 mm, Ø132 mm on a stand, masonry up to Ø162 mm, 5.2 kg. Takes REMS diamond core crowns with UNC 1¼ thread.
180031 R220 REMS Picus S1 diamond core drill Set UDKB 62 Simplex 2 180031 R220
€3,550.48
REMS Picus S1 diamond core drill Set UDKB 62 Simplex 2 180031 R220
The REMS Picus S1 Set UDKB 62 Simplex 2 180031 R220 is the most complete S1 set. 1850 W, 580 rpm, reinforced concrete up to Ø102 mm, Ø132 mm on a stand, masonry up to Ø162 mm, 5.2 kg. Takes REMS diamond core crowns with UNC 1¼ thread.
180032 R220 REMS Picus S1 diamond core drill Set Simplex 2 180032 R220
€3,355.75
REMS Picus S1 diamond core drill Set Simplex 2 180032 R220
The REMS Picus S1 Set Simplex 2 180032 R220 combines the S1 Basic-Pack with the Simplex 2 drill stand. 1850 W, 580 rpm, reinforced concrete up to Ø102 mm, Ø132 mm on a stand, masonry up to Ø162 mm, 5.2 kg. Takes REMS diamond core crowns with UNC 1¼ thread.
181050 R Diamond core bit Ø112 mm x 420 mm REMS 181050 R, UDKB
€293.17
Diamond core bit Ø112 mm x 420 mm REMS 181050 R, UDKB
Induktiv gelötet, wiederbelegbar. Universell einsetzbar zum Trocken- und Nassbohren, handgeführt oder mit Bohrständer. Für viele Materialien, z. B. Beton, Stahlbeton, Mauerwerk aller Art, Naturstein, Asphalt, Estrich aller Art. Anschlussgewinde UNC 11/4 innen…
181103 R Diamond core bit set UDKB 62+102+125 REMS 181103 R
€822.10
Diamond core bit set UDKB 62+102+125 REMS 181103 R
Induktiv gelötet, wiederbelegbar. Universell einsetzbar zum Trocken- und Nassbohren, handgeführt oder mit Bohrständer. Für viele Materialien, z. B. Beton, Stahlbeton, Mauerwerk aller Art, Naturstein, Asphalt, Estrich aller Art. Anschlussgewinde UNC 11/4 innen…
181113 R Diamond core bit set UDKB LS 62+102+125 REMS 181113 R
€904.48
Diamond core bit set UDKB LS 62+102+125 REMS 181113 R
Lasergeschweißt, hochtemperaturbeständig. Universell einsetzbar zum Trocken- und Nassbohren, handgeführt oder mit Bohrständer. Für viele Materialien, z. B. Beton, Stahlbeton, Mauerwerk aller Art, Naturstein, Asphalt, Estrich aller Art. Anschlussgewinde UNC 11…
181435 R Diamond core bit Ø82 mm x 420 mm REMS 181435 R, UDKB LS laser-welded
€263.59
Diamond core bit Ø82 mm x 420 mm REMS 181435 R, UDKB LS laser-welded
Lasergeschweißt, hochtemperaturbeständig. Universell einsetzbar zum Trocken- und Nassbohren, handgeführt oder mit Bohrständer. Für viele Materialien, z. B. Beton, Stahlbeton, Mauerwerk aller Art, Naturstein, Asphalt, Estrich aller Art. Anschlussgewinde UNC 11…
