Magnetic drilling machine, 200 mm, 220 V. Euroboor TUBE.200S/T - 1/8, M3

Name: Magnetic drilling machine, 200 mm, 220 V. Euroboor TUBE.200S/T - 1/8, M3
Brand: EUROBOOR
SKU: TUBE.200S/T

★ 0.0 (0 reviews) • Sold 0

Imported from: Netherlands

Magnetic drilling machine, annular cutters max. dia 200 millimeter, power supply tension 220 - 240 Volt, power supply frequency 50 - 60 Hertz, rotation direction bidirectional.

SKU: TUBE.200S/T

0 đ

Stock status: Hết hàng

Price includes VAT

Download PDF catalog

Description

Extreme drilling and tapping on large pipes Until recently, Ø 55 mm was the upper limit in the TUBE range. Euroboor has added two heavy-duty machines for drilling larger holes in pipe work, the TUBE.100S+/T and the TUBE.200S/T, with the TUBE.200S/T as the top-end model.

The Euroboor TUBE.200S/T is designed for heavy-duty drilling of holes up to Ø 200 mm (8”) and tapping up to M48 (1 7/8”) on pipes and tubes, but can also be used on flat materials. Thanks to its pivoting permanent magnet, the TUBE.200S/T mounts securely on pipes with a minimum diameter of Ø 240 mm (9 7/16”), even on material as thin as 3.5 mm (1/8").

This makes the TUBE.200S/T particularly suitable for demanding applications in metalworking. The machine is powered by a powerful 2,800 W (25 A) motor. The adjustable speed control and right/left rotation allow accurate matching of speed and torque to the cutter and material.

The brushless motor provides efficient, consistent performance with lower wear, while the oil-lubricated 4-speed gearbox and advanced electronics offer overload protection and help protect the machine, tool, workpiece and operator, even under unstable power conditions. A digital display gives you detailed information about your machine while working.

Meanwhile, the GYRO-TEC safety system shuts down the machine in case of sudden movement or excessive vibration, reducing the risk of damage and unplanned downtime, and improving user safety. The TUBE.200S/T is the right choice when pipe work demands maximum capacity, control, and safety.

EAN: 8720999139742

Specification	Value
Order code	TUBE.200S/T
EAN code	8720999139742
minimum diameter threading (inch)	1/8
minimum diameter threading (millimeter)	M3
maximum diameter threading (inch)	1 7/8
maximum diameter threading (millimeter)	M48
minimum diameter annular cutters (inch)	7/16
minimum diameter annular cutters (millimeter)	12
maximum diameter annular cutters (inch)	8
maximum diameter annular cutters (millimeter)	200
minimum diameter countersinking (inch)	3/8
minimum diameter countersinking (millimeter)	10
maximum diameter countersinking (inch)	8 5/64
maximum diameter countersinking (millimeter)	205
minimum diameter twist drills (inch)	1/16
minimum diameter twist drills (millimeter)	2
maximum diameter twist drills (inch)	2
maximum diameter twist drills (millimeter)	50
connection 1 model	inside
connection 1 size (inch)	1 1/4
connection 1 size (millimeter)	31.75
connection 2 morse taper / drill chuck class	MT4
connection 1 type	Weldon
connection 2 model	outside
connection 2 type	morse taper
stroke (inch)	10 1/16
stroke (millimeter)	255
magnet length (inch)	13 5/16
magnet length (millimeter)	338
magnet width (inch)	17 3/16
